A5000/A4000
41
value function
0 off
1 portamento rate/time
2 LFO S/H speed
3 AD in L&R pan
4 AD in L&R level
5 program level
6 effect1 output level
7 effect1 pan
8 effect1-parameter1
... ...
23 effect1-parameter16
24 effect2 output level
25 effect2 pan
26 effect2-parameter1
... ...
41 effect2-parameter16
42 effect3 output level
43 effect3 pan
44 effect3-parameter1
... ...
59 effect3-parameter16
60 effect1 width
61 effect2 width
62 effect3 width
63 program LFO depth
64 AD in L pan
65 AD in R pan
66 AD in L level
67 AD in R level
68 program control1 range
... ...
71 program control4 range
72 effect4-parameter1
... ...
87 effect4-parameter16
88 effect4 output level
89 effect4 pan
90 effect4 width
91 effect5-parameter1
... ...
106 effect5-parameter16
107 effect5 output level
108 effect5 pan
109 effect5 width
110 effect6-parameter1
... ...
125 effect6-parameter16
126 effect6 output level
127 effect6 pan
(*10) No assignment when the first byte is $00
2.1.2 Sample Bank Parameter
P1 P2 P3 P4 P5 P6 data size data value name
0 [Common]
1 0 — — — — UL*4 — reserved
1 1 — — — — UC 0-127 number of assigned samples
1 2 0-126 — — — UC*16 c assigned sample name
(read only)(*2)
1 3 0-126 — — — UL — reserved
1 4 0-88 — — — UC 0,1 sample bank value enable (*1)
2 [Sample Parameter]
(*1) 0-88 of P3 refers to P2 of the “Sample Parameter” block.
(*2) No assignment when the first byte is $00.
2.1.3 Sample Parameter
P1 P2 P3 P4 P5 P6 data size data value name
0 [Common]
1 0 0-1 — — — UC*16 c linked wave object name L,R
(read only) (*1)
1 1 0-1 — — — UL — reserved
1 2 0-1 — — — UL — reserved
2 [Sample Parameter]
(*1) No assignment when the first byte is $00.
2.1.4 Parameter Block
[Common]
P1 P2 P3 P4 P5 P6 data size data value name
0 0 — — — — UC 16,17,20 object type (*1) (read only)
0 1 — — — — UC — reserved
0 2 — — — — UC*16 c name (read only)
0 3 — — — — UC — reserved
0 4 — — — — UL — reserved
(*1) sample:16, sample bank:17, program:20
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
(A5000 only)
[Sample Parameter]
P1 P2 P3 P4 P5 P6 data size data value name
2 0 0-127 — — — UC 0,1 linked to program1-128 (read
only)
2 1 — — — — UC 0,1 sample bank member (*5)
(read only)
2 2 — — — — UC 0-2 0:stereo,1:mono,2:expanded
(*1) (read only)
2 3 — — — — UC 0-32 MIDI receive channel (*6)
2 4 — — — — UC 0-13 pitch bend type
2 5 — — — — UC 0-24 pitch bend range
2 6 0-1 — — — UC 0-127 original key L,R
2 7 0-1 — — — US 1-65535 sampling frequency L,R (Hz)
2 8 0-1 — — — SC +/-63 fine tune L,R
2 9 — — — — SC +/-127 coarse tune
2 10 — — — — UC 0-127,128 key range high ( >=low)(*2)
2 11 — — — — SC -1,0-127 key range low ( <=high)(*3)
2 12 — — — — UC 0-5 loop mode
2 13 — — — — UL 0-16777215 wave start address
2 14 0 — — — UL 0-16777215 wave length (end - start +1)
2 15 — — — — UL 0-16777215 wave end address ( > start)
2 16 — — — — UL 0-16777215 loop start address
2 17 0 — — — UL 0-16777215 loop length (end -start +1)
2 18 — — — — UL 0-16777215 loop end address ( > start)
2 19 — — — — SC +/-63 start address velocity sensitivity
2 20 — — — — US 8000-15999 loop tempo 80.00-159.99
2 21 — — — — UC 0-16 filter type (*7)
2 22 — — — — UC 0-127 filter cutoff frequency
2 23 — — — — UC 0-31 filter Q/width
2 24 0-1 — — — SC 0-127 cutoff key scaling break point
1,2 (1<=2)
2 25 0-1 — — — SC 0 +/-127 cutoff key scaling level 1,2
2 26 — — — — SC +/-63,64-68 cutoff velocity sensitivity (*4)
2 27 — — — — SC +/-63,64-68 Q/width velocity sensitivity (*4)
2 28 — — — — UC 0,1 fixed pitch on
2 29 — — — — SC +/-7 detune
2 30 — — — — SC +/-63 dephase
2 31 — — — — SC +/-63 expand width
2 32 — — — — UC 0-63 random pitch
2 33 — — — — UC 0-127 sample level
2 34 — — — — SC -64,+/-63 pan (*10)
2 35 — — — — UC 0-127 velocity low limit
2 36 — — — — SC +/-127 velocity offset
2 37 — — — — UC 0-127 velocity range high ( >=low)
2 38 — — — — UC 0-127 velocity range low ( <=high)
2 39 0-1 — — — UC 0-127 level key scaling break point 1,2
(1<=2)
2 40 0-1 — — — UC 0-127 level key scaling level 1,2
2 41 — — — — SC +/-127 velocity sensitivity
2 42 — — — — UC 0-5 sample portamento type
2 43 — — — — UC 0,1 mono mode
2 44 — — — — UC 0,1 key x-fade on
2 45 — — — — — — reserved
2 46 — — — — UC 0-127 velocity x-fade low
2 47 — — — — UC 0-127 velocity x-fade high
2 48 — — — — UC 0-16 alternate group number (*8)
2 49 — — — — UC 4-58 EQ frequency
2 50 — — — — SC 52-76 EQ gain
2 51 — — — — UC 10-120 EQ width
2 52 — — — — SC +/-63 cutoff distance
2 53 0-2 — — — UC 0-127 FEG rate attack,decay, release
2 54 0-3 — — — SC +/-127 FEG level init,attack,
sustain,release
2 55 — — — — SC +/-7 FEG rate key scaling
2 56 — — — — SC +/-63 FEG rate velocity sensitivity
2 57 — — — — SC +/-63 FEG attack level velocity.
sensitivity
2 58 — — — — SC +/-63 FEG level velocity sensitivity
2 59 0-2 — — — UC 0-127 PEG rate attack,decay, release
2 60 0-3 — — — SC +/-127 PEG level init,attack,
sustain,release
2 61 — — — — SC +/-7 PEG rate key scaling
2 62 — — — — SC +/-63 PEG rate velocity sensitivity
2 63 — — — — SC +/-63 PEG level velocity sensitivity
2 64 — — — — SC +/-63 PEG range
2 65 0-2 — — — UC 0-127 AEG rate attack,decay, release
2 66 0-1 — — — UC 0-127 AEG sustain level
2 66 3 — — — — — reserved
2 67 — — — — SC +/-7 AEG rate key scaling
2 68 — — — — SC +/-63 AEG rate velocity sensitivity
2 69 — — — — UC 0-2 AEG attack mode
2 70 — — — — UC 0-3 LFO wave
2 71 — — — — UC 0-127 LFO speed
2 72 — — — — UC 0-127 LFO delay time
2 73 — — — — UC 0,1 LFO sync on
2 74 — — — — UC 0,1 LFO pitch mod phase invert on
2 75 — — — — UC 0,1 LFO cutoff mod phase invert on
2 76 — — — — UC 0-127 cutoff mod depth
2 77 — — — — UC 0-127 pitch mod depth
2 78 — — — — UC 0-127 amplitude mod depth
2 79 — — — — UC 0-12 output1 (*9)
2 80 — — — — UC 0-127 output1 level
2 81 — — — — UC 0-12 output2 (*9)
2 82 — — — — UC 0-127 output2 level
2 83 0-5 0 — — UC 0-126 control device 1-6
2 83 0-5 1 — — UC 0-36 control function 1-6 (*11)
2 83 0-5 2 — — UC 0-3 control type 1-6
