A5000/A4000
42
2 83 0-5 3 — — SC +/-63 control range 1-6
2 84 — — — — SC +/-31 filter gain
2 85 — ———UC 0-2 EQ Type
2 86 — — — — — — reserved
2 87 — — — — UC 1-127 sample portamento rate
2 88 — — — — UC 1-127 sample portamento time
(*1) mono samples for which 2:detune or dephase is not +/-0.
(*2) 128:”=Orig”
(*3) -1:”=Orig”
(*4) 64-68:”Rnd1"-”Rnd5"
(*5) 1: depends on any sample bank.
(*6) 0-15:A01-16, 16:basic receive channel, 17-32:B01-16 (A5000 only)
(*7)
(Note 8) 0:off
(Note 9)
(Note 10) -64:”Rnd”
(Note 11)
2.2 System Parameter
Each data byte is divided into the upper and lower 4 bits and received/transmitted as 2 bytes
of MIDI data.
(A5000 only)
(A5000 only)
(A5000 only)
value filter type
0 Bypass
1 LowPass1
2 LowPass2
3 HiPass1
4 HiPass2
5 BandPass
6 BandElim
7 LowPass3
8 Peak1
9 Peak2
10 2Peaks
11 2Dips
12 DualLPFs
13 LPF+Peak
14 DualHPFs
15 HPF+Peak
16 LPF+HP
value output1 output2
0 off off
1 stereo out assignL&R
2 effect1 assign1&2
3 effect2 assign3&4
4 effect3 assign5&6
5 assignL&R DIG&OPT
6 assign1&2 stereo out
7 assign3&4 effect1
8 assign5&6 effect2
9 DIG&OPT effect3
10 effect4 effect4
11 effect5 effect5
12 effect6 effect6
value function
0 off
1 pitch mod depth
2 amp mod depth
3 cutoff mod depth
4 cutoff bias
5 filter Q/width
6 pan bias
7 pitch bias
8 level
9 LFO speed
10 LFO delay
11 AEG attack rate
12 AEG release rate
13 PEG attack rate
14 PEG release rate
15 FEG attck rate
16 FEG release rate
17 pitch bend
18 start address
19 FEG level
20 cutoff distance
21 filter gain
22 portamento rate/time
23 AEG decay rate
24 AEG sustain level
25 FEG decay rate
26 FEG init level
27 FEG sustain level
28 PEG decay rate
29 PEG init level
30 PEG sustain level
31 sample control1 range
... ...
36 sample control6 range
originaldata byte b7,b6,b5,b4,b3,b2,b1,b0
MIDI 1st byte 0,0,0,0,b7,b6,b5,b4
data 2nd byte 0,0,0,0,b3,b2,b1,b0
2.2.1 System Parameter
P1 P2 P3 P4 P5 P6 data size data value name
1 1 0 — — — SC +/-63 master fine tune
1 1 1 — — — SC +/-127 master coarse tune
1 1 2 — — — SC +/-127 master transpose
1 1 3 — — — UC 0-17 velocity curve
1 1 4 — — — UC 0-31 MIDI basic receive channel
(*3)
1 1 5 — — — UC 0,1 MIDI basic channel omni on
1 1 6 — — — UC 0,1 MIDI program change
receive enable
1 1 7 0-3 — — UC -1,0-32 knob2-5 control MIDI transmit
channel (*1)
1 1 8 0-3 — — UC 0-120 knob2-5 control device
1 1 9 0-5 — — UC 0-32 fkey1-6 play MIDI transmit
channel (*4)
1 1 10 0-5 — — UC 0-127 fkey1-6 play note number
1 1 11 0-5 — — UC 0-127 fkey1-6 play velocity
1 1 12 — — — SC 52-76 total EQ low boost gain
1 1 13 — — — UC 4-40 total EQ low boost frequency
1 1 14 — — — SC 52-76 total EQ low gain
1 1 15 — — — UC 4-40 total EQ low frequency
1 1 16 — — — UC 10-120 total EQ low width
1 1 17 — — — SC 52-76 total EQ mid gain
1 1 18 — — — UC 4-58 total EQ mid frequency
1 1 19 — — — UC 10-120 total EQ mid width
1 1 20 — — — SC 52-76 total EQ high gain
1 1 21 — — — UC 28-58 total EQ high frequency
1 1 22 — — — UC 10-120 total EQ high width
1 1 23 — — — UC 0-5 stereo to assignable out
1 1 24 — — — UC 0,1 wave address auto length lock
(*2)
1 1 25 — — — UC 0,1 wave address auto zero (*2)
1 1 26 — — — UC 0,1 wave address auto snap (*2)
1 1 27 — — — UC 0-4 stereo output level offset
1 1 28 — — — UC 0,1 audition with easy edit
1 1 29 — — — UC 0,1 audition with effect
1 1 30 — — — UC 0-9 loop remix type
1 1 31 — — — UC 0-7 loop remix variation
1 1 32 — — — UC 0,1 play&load
1 1 33 — — — UC 0,1 progam mode
1 1 34 0-31 — — UC 0-127 multi part A01-B16 program
number1-128 (*5)
1 1 35 — — — UC 0,1 loop remix auto audition
1 1 36 — — — UC 0-7 loop remix zone start point
1 1 37 — — — UC 1-8 loop remix zone end point
( >start)
1 1 38 0-4 — — UC 0-4 assignable output level offset
(*6)
1 1 39 — — — UC 0,1 knob control MIDI out
1 1 40 — — — UC 0,1 fkey play MIDI out
(*1) -1:AUDIRION, 0-15:A01-16, 16:basic receive channel, 17-32:B01-16(A5000 only)
(*2) Of the three, several will not sound simultaneously.
(*3) 0-15:A01-A16, 16-31:B01-B16 (A5000 only)
(*4) 0-15:A01-A16, 16:basic receive channel, 17-32:B01-16(A5000 only)
(*5) A4000, P4=0-15
(*6) 4000, P4=0-1
2.3 Switch Remote
Data bytes are not divided, but are received as 1 byte of MIDI data.
2.3.1 Switch Remote
P1 P2 P3 P4 P5 P6 data size data value name
0 0 0 0 0 0 UC 0-127 FKEY1 (*1)
1 0 0 0 0 0 UC 0-127 FKEY2 (*1)
2 0 0 0 0 0 UC 0-127 FKEY3 (*1)
3 0 0 0 0 0 UC 0-127 FKEY4 (*1)
4 0 0 0 0 0 UC 0-127 FKEY5 (*1)
5 0 0 0 0 0 UC 0-127 FKEY6 (*1)
6 0 0 0 0 0 UC 0-127 [COMMAND/EXIT] (*1)
7 0 0 0 0 0 UC 0-127 [ASSIGNABLE] (*1)
8 0 0 0 0 0 UC 0-127 [AUDITION] (*1)
9 0 0 0 0 0 UC 0-127 [PLAY] (*1)
10 0 0 0 0 0 UC 0-127 [EDIT] (*1)
11 0 0 0 0 0 UC 0-127 [REC] (*1)
12 0 0 0 0 0 UC 0-127 [DISK] (*1)
13 0 0 0 0 0 UC 0-127 [UTILITY] (*1)
14 0 0 0 0 0 UC 0-127 KNOB1 SW (*1)
15 0 0 0 0 0 UC 0-127 KNOB2 SW (*1)
16 0 0 0 0 0 UC 0-127 KNOB3 SW (*1)
17 0 0 0 0 0 UC 0-127 KNOB4 SW (*1)
18 0 0 0 0 0 UC 0-127 KNOB5 SW (*1)
20 0 0 0 0 0 UC 0-127 [COMMAND/EXIT]+
[ASSIGNABLE] (*1)
21 0 0 0 0 0 UC 0-127 [COMMAND/EXIT]+
[AUDITION] (*1)
123 0 0 0 0 0 UC 0-127 KNOB1 ENCODER
124 0 0 0 0 0 UC 0-127 KNOB2 ENCODER
125 0 0 0 0 0 UC 0-127 KNOB3 ENCODER
126 0 0 0 0 0 UC 0-127 KNOB4 ENCODER
127 0 0 0 0 0 UC 0-127 KNOB5 ENCODER
(Note 1) 0-63: Switch off, 64-127: Switch on
