8-69
1. Arrow mark
1. Flèche
1. Flecha
1. Tapered nut
1. Écrou conique
1. Tuerca cónica
EBU00828
Wheel installation
When installing a wheel, reverse the removal pro-
cedure.
NOTE:
_
The arrow mark on the tire must point toward
the rotating direction of the wheel.
_
1. Tapered wheel nuts are used for both front
and rear wheels. Install the nut with its ta-
pered side towards the wheel.
2. Tighten the wheel nuts to the specified
torque.
Wheel nut torque:
Front: 55 Nm (5.5 m·kgf)
Rear: 55 Nm (5.5 m·kgf)
EE.book Page 69 Monday, June 25, 2001 2:27 PM
