Periodic maintenance and adjustment
7-32
7
6. Install the headlight unit by install-
ing the screws.
7. Have a Yamaha dealer adjust the
headlight beam if necessary.
EAU70540
Brake/tail light
This model is equipped with an LED-
type brake/tail light.
If the brake/tail light does not come on,
have a Yamaha dealer check it.
EAU24215
Replacing a turn signal light
bulb
1. Remove the turn signal light lens
by removing the screws.
2. Remove the burnt-out bulb by
pushing it in and turning it coun-
terclockwise.
1. “TOP” mark
1. Screw
2. Turn signal light lens
