WARNING
This unit contains high pressure nitrogen gas.
Mishandling can cause explosion.
Read owner’s manual for instructions.
Do not incinerate, puncture or open.
2DX-22259-00
VACUUM HOSE ROUTING
34B-21684-00
INTAKE MANIFOLD
PRESS. SENSOR
5RU-21686-00
EMISSION HOSE ROUTING
THROTTLE BODY
CANISTER
ATMOSPHERE
FUEL TANK
TIRE INFORMATION
Cold tire normal pressu re shou ld b e set
as follow s.
FRONT
REAR
: 225 kPa, {2.25 kgf/cm²}, 33 psi
: 250 kPa, {2.50 kgf/cm²}, 36 psi
1TP-21668-00
WARNING
BEFORE YOU OPERATE THIS VEHICLE, READ
THE OWNER’S MANUAL AND ALL LABELS.
NEVER CARRY A PASSENGER. You increase your
risk of losing control if you carry a passenger.
ALWAYS WEAR AN APPROVED MOTORCYCLE
HELMET, eye protection, and protective clothing.
1TP-2118K-00
1 California only 2 California only
3 Bolt R-Spec 4
5
