Yamaha CDX-396 - DISPLAY DATA DETAILS; Display Pin Connections; Display Grid Assignments; Display Anode Connections

CDX-396/496
CDX-396/496
V401 : 9-MT-133GK
NOTE 1) F1, F2 ..........Filament
2) NP ...............No pin
3) NC ...............No connection
4) P1~P10 .......Datum Line
5) 1G~9G .........Grid
PIN CONNECTION
PIN NO.
CONNECTION
1
F1
2
F1
3
NP
4
9G
6
7G
5
8G
7
6G
8
5G
9
4G
10
3G
11
2G
12
1G
13
NC
14
NC
15
NC
16
NC
17
NC
18
NC
PIN NO.
CONNECTION
19
NC
20
NC
21
P12
22
P11
24
P9
23
P10
25
P8
26
P7
27
P6
28
P5
29
P4
30
P3
31
P2
32
P1
33
NP
34
F2
35
F2
GRID ASSIGNMENT
PATTERN AREA
1
35
ANODE CONNECTION
■ DISPLAY DATA
12
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
7G
a
b
c
d
e
f
g
—
5
6
—
—
7G
a
b
c
d
e
f
g
—
7
8
—
—
6G
TOTAL
REMAIN
—
—
—
—
—
—
9
10
11
—
5G
a
b
c
d
e
f
g
—
12
INDEX
—
—
4G
a
b
c
d
e
f
g
—
13
14
—
—
3G
a
b
c
d
e
f
g
:
15
PEAK
—
—
2G
a
b
c
d
e
f
g
—
16
17
—
—
1G
SINGLE
FULL
REPEAT
B1
B2
B3
B4
B5
S1
18
19
20
9G
PROGRAM
PROGRAM
RANDOM
RANDOM
A
B
SPACE
—
—
1
2
3
4
