Yamaha CDX-396 - CDX-396 Main PCB Parts

CDX-396/496
CDX-396/496
26
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
* V5003700 P.C.B. MAIN(UC)
* V5003800 P.C.B. MAIN(R)
* V5003900 P.C.B. MAIN(A)
* V5004000 P.C.B. MAIN(BG)
CB1 V2731000 CN.FMN 16P
CB2 VB390200 CN.BS.PIN 6P
CB3 VB390100 CN.BS.PIN 5P
CB101 VT707200 L.EMIT TOTX178
CB200 VK024900 CN.BS.PIN 5P
CB201 Vi878300 CN.BS.PIN 5P
CB202 VP245600 CN 2P
CB203 VG879900 CN.BS.PIN 2P
CB300 VU283000 CN.BS.PIN 30P
CB301 VU273000 CN.BS.PIN 30P
C1 VJ599100 C.CE.TUBLR 0.1uF 50V
C3 UA654470 C.MYLAR 0.047uF 50V
C4 UR818100 C.EL 100uF 6.3V
C5 UR818100 C.EL 100uF 6.3V
C6 UR866100 C.EL 1uF 50V
C7 VJ599100 C.CE.TUBLR 0.1uF 50V
C8 VJ599100 C.CE.TUBLR 0.1uF 50V
C9 UA953100 C.MYLAR 1000pF 50V
C10 VJ599100 C.CE.TUBLR 0.1uF 50V
C11 VF466700 C.CE.TUBLR 47pF 50V
C12 UA655100 C.MYLAR 0.1uF 50V
C13 VG278400 C.CE.TUBLR 220pF 50V
C14 UN865470 C.EL 0.47uF 50V
C15 UA655100 C.MYLAR 0.1uF 50V
C16 UA953120 C.MYLAR 1200pF 50V
C17 UA953270 C.MYLAR 2700pF 50V
C18 UN866470 C.EL 4.7uF 50V
C19 UR837470 C.EL 47uF 16V
C20 VJ599100 C.CE.TUBLR 0.1uF 50V
C21 UR818100 C.EL 100uF 6.3V
* C22 V4749000 C.EL 150uF 6.3V
C23 VF467000 C.CE.TUBLR 1000pF 50V
C24 VJ599100 C.CE.TUBLR 0.1uF 50V
C25 UR818100 C.EL 100uF 6.3V
C26 UR818100 C.EL 100uF 6.3V
C27 UR838100 C.EL 100uF 16V
* C28 V4749000 C.EL 150uF 6.3V
C29 UA953330 C.MYLAR 3300pF 50V
C30 UA655100 C.MYLAR 0.1uF 50V
C31 VG278700 C.CE.TUBLR 390pF 50V
C32 UA655100 C.MYLAR 0.1uF 50V
C33 VJ599100 C.CE.TUBLR 0.1uF 50V
C34 UA954120 C.MYLAR 0.012uF 50V
* C35 V4749000 C.EL 150uF 6.3V
C36 UA655100 C.MYLAR 0.1uF 50V
* C37 UN865220 C.EL 0.22uF 50V
C38 UA655100 C.MYLAR 0.1uF 50V
C39 VJ599100 C.CE.TUBLR 0.1uF 50V
C42 VJ599100 C.CE.TUBLR 0.1uF 50V
C43 VA761400 C.CE 47pF 50V
C44 VA761400 C.CE 47pF 50V
C46 UR866100 C.EL 1uF 50V
C47 UR866100 C.EL 1uF 50V
C48 UR866100 C.EL 1uF 50V
C49 UR866100 C.EL 1uF 50V
C50 UR818470 C.EL 470uF 6.3V
C51 VJ599100 C.CE.TUBLR 0.1uF 50V
C54 VJ599100 C.CE.TUBLR 0.1uF 50V
C55 UR818100 C.EL 100uF 6.3V
C56 UR818100 C.EL 100uF 6.3V
C60 VJ599100 C.CE.TUBLR 0.1uF 50V
C62 VJ599100 C.CE.TUBLR 0.1uF 50V
C63 VJ599100 C.CE.TUBLR 0.1uF 50V
C100 UA952100 C.MYLAR 100pF 50V
* C101 V4850700 C.MYLAR 560pF 50V
* C102 V4850700 C.MYLAR 560pF 50V
C103 UA952100 C.MYLAR 100pF 50V
C104 UA954180 C.MYLAR 0.018uF 50V
C105 V2680700 C.MYLAR 3300pF 50V
C106 V2680700 C.MYLAR 3300pF 50V
C107 UA954180 C.MYLAR 0.018uF 50V
C108 VG287300 C.EL 22uF 50V
C109 VG287300 C.EL 22uF 50V
C118 VJ599100 C.CE.TUBLR 0.1uF 50V
C119 UA953100 C.MYLAR 1000pF 50V
C120 UA953100 C.MYLAR 1000pF 50V
C124 UR818100 C.EL 100uF 6.3V
C125 UR818100 C.EL 100uF 6.3V
C126 UR818100 C.EL 100uF 6.3V
C127 UR818100 C.EL 100uF 6.3V
C200 VJ599100 C.CE.TUBLR 0.1uF 50V
C201 UR866470 C.EL 4.7uF 50V
C202 UR866470 C.EL 4.7uF 50V
C203 UR865680 C.EL 0.68uF 50V
C204 UR818100 C.EL 100uF 6.3V
C205 UR818100 C.EL 100uF 6.3V
C206 UR866470 C.EL 4.7uF 50V
C207 UR739470 C.EL 4700uF 16V
C208 UR818100 C.EL 100uF 6.3V
C209 UR838220 C.EL 220uF 16V
C210 VG287900 C.EL 470uF 16V
C211 VG288300 C.EL 4700uF 16V
C212 UR828100 C.EL 100uF 10V
C213 UR866470 C.EL 4.7uF 50V
C214 UR866470 C.EL 4.7uF 50V
C215 FG644100 C.CE 0.01uF 50V
C216 FG644100 C.CE 0.01uF 50V
C217 UR867470 C.EL 47uF 50V
C218 FG644100 C.CE 0.01uF 50V
C219 UR868100 C.EL 100uF 50V
C220 VS741700 C.CE.SAFTY 0.01uF 275V
C221 VS741700 C.CE.SAFTY 0.01uF 275V
CDX-396 MAIN P.C.B.
