Yamaha CDX-396 - CDX-496 Main PCB Parts

CDX-396/496
CDX-396/496
Schm
Ref. PART NO. Description
Schm
Ref. PART NO. Description
29
* New Parts
New Parts
*
C214 UR866470 C.EL 4.7uF 50V
C215 FG644100 C.CE 0.01uF 50V
C216 FG644100 C.CE 0.01uF 50V
C217 UR867470 C.EL 47uF 50V
C218 FG644100 C.CE 0.01uF 50V
C219 UR868100 C.EL 100uF 50V
C220 VS741700 C.CE.SAFTY 0.01uF 275V
C221 VS741700 C.CE.SAFTY 0.01uF 275V
C222 VS741700 C.CE.SAFTY 0.01uF 275V
C300 VJ599100 C.CE.TUBLR 0.1uF 50V
C301 UR818100 C.EL 100uF 6.3V
C302 VG278700 C.CE.TUBLR 390pF 50V
C303 VG278700 C.CE.TUBLR 390pF 50V
C304 VG278700 C.CE.TUBLR 390pF 50V
C305 VG278700 C.CE.TUBLR 390pF 50V
C306 UM388100 C.EL 100uF 10V
C307 VJ599100 C.CE.TUBLR 0.1uF 50V
C401 VG279100 C.CE.TUBLR 1200pF 16V
D100 VD631600 DIODE 1SS133,176,HSS104
D101 VD631600 DIODE 1SS133,176,HSS104
D200 VD631600 DIODE 1SS133,176,HSS104
D201 VD631600 DIODE 1SS133,176,HSS104
D202 VG438000 DIODE.ZENR MTZJ6.2B 6.2V
* D203 VG437000 DIODE.ZENR MTZJ4.7A 4.7V
D204 VS997800 DIODE 1T2
D205 VG437400 DIODE.ZENR MTZJ5.1B 5.1V
D206 VG442200 DIODE.ZENR MTZJ22C 22V
D207 VS997800 DIODE 1T2
D208 VS997800 DIODE 1T2
D209 VS997800 DIODE 1T2
D210 VS997800 DIODE 1T2
D211 VS997800 DIODE 1T2
D212 VS997800 DIODE 1T2
D213 VS997800 DIODE 1T2
D214 VS997800 DIODE 1T2
D215 VS997800 DIODE 1T2
D216 VS997800 DIODE 1T2
D217 VS997800 DIODE 1T2
* D250 VG438500 DIODE.ZENR MTZJ7.5A 7.5V
D300 VD631600 DIODE 1SS133,176,HSS104
D301 VD631600 DIODE 1SS133,176,HSS104
D302 VD631600 DIODE 1SS133,176,HSS104
D303 VD631600 DIODE 1SS133,176,HSS104
D304 VD631600 DIODE 1SS133,176,HSS104
HS201 VA119100 HEAT.SINK
HS202 VA119100 HEAT.SINK
* IC1 XW249A00 IC AN8882SB
* IC2 XW244A00 IC AN8785SB
* IC3 XW915A00 IC MN35511AL
IC101 XA987A00 IC NJM2068D-D
IC102 XA987A00 IC NJM2068D-D
IC105 Xi249A00 IC BA15218
IC200 XD201A00 IC M5290P
* IC300 XY240A00 IC CPU UPD78043FGF-072
IC301 XS070A00 IC S-24C01ADP EEPROM
JK100 V2700900 JACK.PHONE JY-6317-03-030GD
L201 VV900900 FLTR 3071-012-0
* PJ100 V4925200 JACK.PIN 2P
Q1 iB054430 TR 2SB544 D,E,F,G
Q3 iC287820 TR 2SC2878 A,B
Q4 iC287820 TR 2SC2878 A,B
Q100 iC287820 TR 2SC2878 A,B
Q101 iC287820 TR 2SC2878 A,B
Q102 iC287820 TR 2SC2878 A,B
Q103 iC287820 TR 2SC2878 A,B
Q201 iA093320 TR 2SA933S Q,R
Q202 VS883300 TR 2SB1565 E,F
Q203 VS883400 TR 2SD2394 E,F
Q204 iA093320 TR 2SA933S Q,R
Q250 iA093320 TR 2SA933S Q,R
Q300 iA093320 TR 2SA933S Q,R
Q301 iC174020 TR 2SC1740S R,S
R118 HV755120 R.CAR.FP 120 1/4W
R125 HV755120 R.CAR.FP 120 1/4W
R203 HV755100 R.CAR.FP 100 1/4W
R206 HV755100 R.CAR.FP 100 1/4W
R208 Vi868300 R.FUS 0.68 1/6W
R217 HV755150 R.CAR.FP 150 1/4W
R401 Vi868300 R.FUS 0.68 1/6W
SW200 VZ364100 SW.PUSH SDDLD1-A2-F-1
SW201 VL908000 VOLT.SELCT ESE-370(R)
SW300 VG392900 SW.TACT SKHVAA
SW301 VG392900 SW.TACT SKHVAA
SW302 VG392900 SW.TACT SKHVAA
SW303 VG392900 SW.TACT SKHVAA
SW304 VG392900 SW.TACT SKHVAA
SW305 VG392900 SW.TACT SKHVAA
SW306 VG392900 SW.TACT SKHVAA
SW307 VG392900 SW.TACT SKHVAA
SW308 VG392900 SW.TACT SKHVAA
SW309 VG392900 SW.TACT SKHVAA
SW310 VG392900 SW.TACT SKHVAA
SW311 VG392900 SW.TACT SKHVAA
SW312 VG392900 SW.TACT SKHVAA
SW313 VG392900 SW.TACT SKHVAA
SW314 VG392900 SW.TACT SKHVAA
SW315 VG392900 SW.TACT SKHVAA
SW316 VG392900 SW.TACT SKHVAA
SW317 VG392900 SW.TACT SKHVAA
* T200 XW859A00 TRANS.PWR (R)
* T200 XW861A00 TRANS.PWR (BG)
U300 V2856200 L.DTCT PIC-28043TH2
V300 VR061600 FL.DSPLY 9-MT-133GK
XL1 VJ719800 RSNR.CRYS 16.9344MHz
XL300 VU763600 RSNR.CE 5MHz
V3750100 PIN L=50(R)
VQ948800 SHEET.FL GD
VZ156000 SPACER.FL t4x5x23
VN008600 SCR.TERM 8.3x13
CDX-496 MAIN P.C.B.
