■ MECHANICAL PARTS
31
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
1-3 MF130100 FLEXIBLE FLAT CABLE 30P 100mm
* 1-20 V4200600 FRONT PANEL BL
* 1-20 V4200700 FRONT PANEL TI
* 1-22 V4210400 WINDOW PANEL,LID
1-23 VZ494400 BUTTON 11x22 BL
1-23 VZ494500 BUTTON 11x22 TI
* 1-25 V4201400 BUTTON BL
* 1-25 V4201500 BUTTON TI
* 1-26 V4201200 BUTTON,4P BL
* 1-26 V4201300 BUTTON,4P TI
* 1-27 V4201000 BUTTON BL
* 1-27 V4201100 BUTTON TI
* 1-31 V4201600 SUPPORT,PANEL
1-40 EP630290 BIND HEAD P-TITE SCREW 3x6 FCRM3-BL
* 2 V5003700 P.C.B.ASS'Y MAIN (UC)
* 2 V5003800 P.C.B.ASS'Y MAIN (R)
* 2 V5003900 P.C.B.ASS'Y MAIN (A)
* 2 V5004000 P.C.B.ASS'Y MAIN (BG)
5 VZ573200 CD MECHANISM UNIT KSL-2130CCM
8 V2296800 POWER CORD ASS'Y (A)
8 V2363800 POWER CORD ASS'Y (UC)
8 VN363700 POWER CORD ASS'Y (G)
8 VV437300 POWER CORD ASS'Y (B)
8 VZ542500 POWER CORD ASS'Y (R)
9 V2438700 CORD STOPPER #10P1
11 V2017700 CONNECTOR,FLAT CABLE 16P 280mm
* 13 MF706120 IDC CABLE ASS'Y 6P 120mm
14 MF705120 IDC CABLE ASS'Y 5P 120mm
20 VZ151800 CHASSIS,MAIN ALL
* 21 V4410100 REAR PANEL (UC)
* 21 V4410200 REAR PANEL (R)
* 21 V4410300 REAR PANEL (BG)
* 21 V4410400 REAR PANEL (A)
23 VZ151900 TOP COVER BL
23 VZ152000 TOP COVER TI
* 26 V4200800 LID,CDX BL
* 26 V4200900 LID,CDX TI
27 VQ780300 LEG D60xH16
28 VS037900 SHEET,TRAY B
35 VU981200 SUPPORT,P.C.B.No.3596
36 VS257300 PLATE,R (R)
37 VZ262200 SUPPORT PU
50 VU590000 BINDING TIE CBTD001B
55 V2113100 SPACER
60 21991500 PW HEAD S-TITE SCREW 4x8-10 FCRM3-BL BL
60 VH313200 BW HEAD S-TITE SCREW 4x8-10 FNM3-BL TI
61 EP600250 BIND HEAD B-TITE SCREW 3x8 ZMC2-Y
62 EP630640 BIND HEAD P-TITE SCREW 3x20 FCRM3-BL
63 VN413300 BIND HEAD BONDING B-T.SCREW 3x8 MFZN2-BL
64 EP600140 BIND HEAD B-TITE SCREW 3x10 MFZN2-BL (R)
66 EP630400 FLAT HEAD B-TITE SCREW 3x6 FCRM3-BL
67 V2728500 BIND HEAD S-TITE SCREW 4x7 MFZN2-BL
69 EP600830 BIND HEAD B-TITE SCREW 3x8 FCRM3-BL
