Yamaha CRX-E100 - Page 19

ABCDEFGH
1
2
3
4
5
6
RX-E100
P. C. B. MAIN ( 2 )
R L
MD
AUX
R L
TAPE
CD
FREQUENCY
STEP
(R only)
FROM : TUNER
TUL
TE
TUR
12V
MUT-T
CE
DAT-I
CLK
DAT-D
STA
ST-MO
TO : MAIN (1)
ST/MO
ST8
MUT-T
DAT-I
L
E
R
15V
—15V
CLK
DAT-O
CE
DES
DG
ETU
W101
115
30 16
1
9
P. C. B. MAIN ( 3 )
VOLUME
V-DN
V-UP
GND
GND
E
RI
RO
E
LO
LI
TO : MAIN (1)
W102
P. C. B. MAIN ( 4 )
FROM : POWER
TRANSFORMER
+15V E15 PS +B E —B —B E +B
TO : MAIN (1)
W103
—VP VG F1 F2
FROM : OPERATION
P. C. B. MAIN ( 6 )
BR
TO : MAIN (8)
J, U, C, A, B, G models
W110
TO : MAIN (7) R model
W113
BR
TO : MAIN (5) R model
GY
TO : MAIN (8) J, U, C, A, B, G models
W111
W112
GY
FROM : POWER CORD
AC
OUTLET
■ PRINTED CIRCUIT BOARD (Foil side)
CIRCUIT CHANGES BY MARKET.
JU, C R A B G
F100 X X X X X O
J103 O O O O O X
CB101, 102 X X X X X O
J100 O O X O O O
R268 X O X X X X
C126 O O X O O O
C134 X X O X X X
Q101 X X O X X X
R124, 125 X X O X X X
D101 X X O X X X
C117 X X O X X X
SW101 X X O X X X
O : USED
X : NOT USED
E-23/J-21
