CS2X
19
to DM-CN3
LCD back-lit
Component side
Pattern side
LE Circuit Board
LC Circuit Board
Component side
to MK-H
Component side
MKS Circuit Board
to MK-H to MK-L
to DM-CN4
KA
LED3~LED8
Mark
Cathode
Anode
An LE board is located on either of the PN1/2 and PN2/2 circuit boards.
2NA-VU40760 2 ; LE, LC
2NA-VU49440 ; MKS
