Yamaha CS2x Service Manual

3
CS2X
SPECIFICATIONS
KEYBOARD 61 keys with Initial Touch
TONE GENERATOR AWM2 (Wave ROM 16MB)
POLYPHONY 64 notes
MULTITIMBRE 16 (DVA)
PERFORMANCE 256 Presets, 256 Users
VOICE Normal Voices Total 779
XG 584
TG300B 614
Voices For Performances
Drum Voices Total 30
XG 20
TG300B 10
ARPEGGIATOR 40
EFFECT Reverb 12
Chorus 14
Variation 62
CONTROLS STANDBY/ON, VOLUME, PITCH, MODULATION, Sound Control Knobs 8, SCENE 1/2,
Numeric Keypad, ENTER, Mode Select (PERFORMANCE, MULTI, STORE, UTILITY),
ARPEGGIATOR, SHIFT/OCTAVE, PART/LAYER +/-, PRESET, USER, PROGRAM +/-, Edit
Parameter Rotary Switch, Parameter Value Up/Down buttons 10
DISPLAY LCD (Back Lit)
TERMINALS PHONES (Stereo Phone), OUTPUT (Phone): L[MONO]/R, DC IN, FOOTVOLUME,
FOOT CONTROLLER, FOOTSWITCH, INPUT , TO HOST, HOST SELECT , MIDI
IN/OUT/THRU
POWER SUPPLY AC adaptor PA-3B*
DIMENSIONS 976(W) x 285(D) x 103(H)mm (38-3/8” x 11-1/4” x 4-1/16”)
WEIGHT 5.7kg (12 lbs., 9 oz.)
ACCESSORIES Yamaha AC Adaptor PA-3B*
Owner’s Manual, Data List
Specifications and descriptions are for information purposes only. Yamaha Corp. reserves the right
to change or modify products or specifications at any time without prior notice.

Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
