Yamaha CS2x Service Manual

41
CS2X
53 1 00...7F FC Vari. Cntrl Depth -64...+63 40(+0)
54 1 00...7F Send Chorus To Reverb 0...127 0
Total size 15
Address Size Data Prameter Name Description Default
(H) (H) (H) value(H)
7# pp 60 1 00...7F MW Filter Control -64...+63 40(+0)
61 1 00...7F MW LFO PMod Depth 0...127 0A(10)
62 1 00...7F MW LFO FMod Depth 0...127 0
63 1 28...58 Bend Pitch Control -24...+24(semitones) 42(+2semitones)
64 1 00...7F FC Filter Control -64...+63 40(+0)
65 1 00 reserved 0 00
66 1 00...7F FC LFO FMod Depth 0...127 0
67 1 00...01 Portamento Switch off(0),on(1) 0(off)
68 1 00...7F Portamento Time 0...127 0
Total size 09
# = BankNo.(0=0x0, 1=0x8)
pp = Performance Number(00...7F)
MIDI Data Table <2-6>
MIDI Parameter Change table (User Performance Layer)
Address Size Data Prameter Name Description Default
(H) (H) (H) value(H)
7$ pp 00 1 00...7F Voice Bank Number MSB 0...127 00
01 1 00...7F Voice Bank Number LSB 0...127 00
02 1 00...7F Voice Number 1...128 00
03 1 00...03 Play Mode mono(0),poly(1) 1(poly)
04 1 28...58 Note Shift -24...+24(semitones) 40(+0)
05 2 00...FF Detune -12.8...+12.7(Hz) 08(+0.0Hz)
1st bit3...0 >> bit7...4 00
07 1 00...7F Volume 0...127 64(100)
08 1 00...7F Velocity Sense Depth 0...127 40(64)
09 1 00...7F Velocity Sens Offset -64...+63 40(+0)
0a 1 00...7F Pan random(0),L63...C...R63 40(C)
0b 1 00...7F Note Limit Low C-2...G8 00(C-2)
0c 1 00...7F Note Limit High C-2...G8 7F(G8)
0d 1 00...7F Chorus Send 0...127 00
0e 1 00...7F Reverb Send 0...127 28(40)
0f 1 00...7F Variation Send off(0),on(1...127) 7F(on)
10 1 00...02 LFO Key Sync FreeRun(0),retrigger(1),-(2) 2(-)
11 1 00...7F Filter Cutoff Freq. -64...+63 40(+0)
12 1 01...7F Filter Resonance -63...+63 40(+0)
13 1 01...7F Amp. EG Attack Time -63...+63 40(+0)
14 1 01...7F Amp. EG Decay Time -63...+63 40(+0)
15 1 01...7F Amp. EG Release Time -63...+63 40(+0)
16 1 00...03 Receive Note(Mute) off(0),on(1) 1(on)
17 1 00...7F PitchEG Initial Level -64...+63 40(+0)
18 1 01...7F PitchEG Attack Time -63...+63 40(+0)
19 1 01...7F PitchEG Release Time -63...+63 40(+0)
1a 1 00...7F PitchEG Release Level -64...+63 40(+0)
1b 1 01...7F Velocity Limit Low 1...127 01
1c 1 01...7F Velocity Limit High 1...127 7F(127)
1d 1 00...7F Amp. EG Sustain Level -64...+63 40(+0)
1e 1 01...7F LFO Speed -63...+63 40(+0)
1f 1 00...7F LFO Wave 0...3(saw,tri,S&H,--) 3(--)
20 1 21...5F LFO AMod Depth -31...+31 40(+0)
21 1 01...7F LFO PMod Depth -63...+63 40(+0)
22 1 31...4F LFO FMod Depth -15...+15 40(+0)
23 1 01...7F FilterEG Attack Time -63...+63 40(+0)
24 1 01...7F FilterEG Decay Time -63...+63 40(+0)
25 1 00...7F FilterEG Sus Level -64...+63 40(+0)
26 1 01...7F FilterEG Release Time -63...+63 40(+0)
27 1 00...7F PitchEG Attack Level -64...+63 40(+0)
28 1 01...7F PitchEG Decay Time -63...+63 40(+0)
29 1 00...7F EQ Bass Gain -12..+12[db] 0x40
2A 1 00...7F EQ Treble Gain -12..+12[db] 0x40
2B 1 04...28 EQ Bass Frequency 32..2.0KHz 0C
2C 1 1C...3A EQ Treble Frequency 500..16.0KHz 36
Total size 2D
pp = Performance Number(00...7F)
$ = 1 ;Bank1Layer1 ,9=Bank2Layer1
2 ;Bank1Layer2 ,A=Bank2Layer2
3 ;Bank1Layer3 ,B=Bank2Layer3
4 ;Bank1Layer4 ,C=Bank2Layer4

Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
