Yamaha CS2x Service Manual

3
CS2X
*
*
*
*
*
*
*
*
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
OVERALL ASSEMBLY CS2X
Overall Assembly (V286010)
10 Upper Case Assembly (V299750)
20 Keyboard Assembly C61 K6 24
30 Angle Bracket 503
40 Bind Head Tapping Screw-B 3.0X8 MFZN2BL 10 01
50 MKR Angle 204
60 Bind Head Tapping Screw-B 3.0X20 MFZN2BL 401
70 Shield Box 11
80 Bind Head Tapping Screw-B 3.0X20 MFZN2BL 201
90 Circuit Board DM
100 Bonding Tapping Screw-B 3.0X10 MFZN2BL 701
110 Bind Head Tapping Screw-B 3.0X8 MFZN2BL 501
112 Bind Head Tapping Screw-B 3.0X12 MFZN2Y 01
114 Cord Holder T18MR (V242290)
120 Cord Binder S-75B 201
130 Jumper Wire P=2.0-C-26SB-6-160 (V361090) 01
135 Ferrite core FR25/15/12-1400L 04
136 Cushion
140 Cord Holder UAMS-09-0 201
150 Lithium Battery CR2032 03
160 Bottom Assembly 12
160a Bottom Board (VU58480)
160b Foot 205Y4179 402
165 Bonding Tapping Screw-B 4.0X10 MFZN2BL 33 01
170 Push Button STANDBY ON 03
180 Name Plate (V353190)
Upper Case Assembly (V299750)
U10 Upper Case
U20 Lens, Back-lit 05
U30 LCD LCD5853H 06
U35 Reflection Sheet 03
U40 Rubber Connector SG 202
U50 Circuit Board LC 11
U55 Spacer 03
U60 Bind Head Tapping Screw-P 3.0X8 MFZN2Y 301
U65 Bind Head Tapping Screw-P 3.0X10 MFZN2BL 301
U70 Key Top Rubber L2 SCENE (1,2) 03
U80 Key Top S1 ARPEGGIO/PART(-)/PRESET/ 05
PART(-)/PROGRAM(-)
U90 Key Top S2 SHIFT/PART(+)/USER/ 05
PROGRAM(+) 05
U100 Key Top T1 0/1/4/7 05
U110 Key Top T2 -/2/5/8 05
U120 Key Top T3 ENTER/3/6/9 05
U130 Key top Rubber PERFORM/MULTI/STORE/ 2
UTILITY 2
U140 Key Top Rubber up/down 06
U160a Circuit Board PN 1/2
U160b Circuit Board PN 2/2
U170 Bind Head Tapping Screw-P 3.0X8 MFZN2Y 20 01
U180 GND Wire (VU57890)
U181 PN-SB GNG Wire (V360098)
U185 Cord Binder S-75B 01
U190 Wheel Assembly (VU64090)
U200 Bind Head Tapping Screw-P 3.0X8 MFZN2Y 401
U210 Knob
VOLUME,ATTACK,HPF CUTOFF, 10
DECAY,LPF CUTOFF,RELEASE, 10
ASSIGN 1/DATA,ASSIGN 2, 10
RESONANCE,Dial 10
U220 LCD Cover
Wheel Assembly (VU64090)
W10 Frame 204
W20 Wheel YS200 203
W30 Spring 01
W40 Wheel Tube 304
W50 Stop Ring 12.0 01
W60 Rotary Variable Resistor RK1631110T54Aĸ10K PITCH 03
--
--
--
VU621100
VU540700
EP600190
VU540900
VJ999700
VU540500
VJ999700
V2783900
VQ049800
EP600190
VE683000
--
CB502030
--
VC362700
V3651400
VR641100
VN103500
VU640800
--
VC999400
VJ254100
CB825380
--
--
V3002700
VU540300
VU421400
VU673400
VS555800
VU407800
VV170400
EP600280
EP630660
VU590900
VU640100
VU640200
VU640300
VU640400
VU640500
V3225500
VU643100
NX820420
NX820430
EP600280
--
--
CB502030
--
EP600280
V3005900
V3002900
--
VQ561400
VF537400
VC792800
CB819020
EW600110
VQ764300
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
W70 Rotary Variable Resistor 10.0K K161100S MODULATION 03
W80 Connector Assembly PH5P-5F 300L+100L (VU55440)
W90 Cord Holder BK-1 (CB06925) 2 01
ACCESSORY
A20 AC Adapter PA-3B JP J 09
A20 AC Adapter PA-3B UC U
A20 AC Adapter PA-3B CEE E 08
VN245400
--
--
VT368600
VT368700
VT368800

Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
