General Specifications
At the time of measurement, all faders are set to nominal. Output impedance of the signal generator is 150Ω.
Frequency response
Fs= 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz @20 Hz–20 kHz, reference to the nominal output level @1 kHz
Total harmonic distortion
Fs= 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
* An 80kHz, 18 dB/octave low pass filter is used to measure total harmonic distortion.
Hum & noise
*2
Fs= 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Dynamic range
Fs= 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
* An IHF-A filter is used to measure dynamic range.
Specifications
Inputs Outputs RL Conditions Min. Typ. Max. Unit
OMNI IN 1-8 OMNI OUT 1-8 600Ω GAIN: +66 dB –0.8 0.0 0.5 dB
Inputs Outputs RL Conditions Min. Typ. Max. Unit
OMNI IN 1-8 OMNI OUT 1-8 600Ω +4 dBu@20 Hz–20 kHz, GAIN: +66 dB 0.12 %
OMNI IN 1-8 OMNI OUT 1-8 600Ω +4 dBu@20 Hz–20 kHz, GAIN: –6 dB 0.05 %
Internal OSC OMNI OUT 1-8 600Ω Full scale output @1 kHz 0.02 %
Internal OSC PHONES
8Ω
Full scale output @1 kHz,
phones level control: max.
0.2 %
Inputs Outputs RL Conditions Min. Typ. Max. Unit
OMNI IN 1-8 OMNI OUT 1-8
600Ω
Rs= 150Ω, GAIN: +66 dB
Master fader at nominal level and one
Ch fader at nominal level.
–128
EIN
*1
*1. EIN stands for Equivalent Input Noise.
*2. An IHF-A filter is used to measure hum & noise level.
dBu
–62 dBu
OMNI IN 1-8 OMNI OUT 1-8
600Ω
Rs= 150Ω, GAIN: –6 dB
Master fader at nominal level and one
Ch fader at nominal level.
–90 -85 dBu
All Inputs OMNI OUT 1-8
600Ω
Rs= 150Ω, GAIN: –6 dB
Master fader at nominal level and all
OMNI IN1-8 in faders at nominal level.
-76 dBu
— OMNI OUT 1-8 600Ω Residual output noise, ST master off. –92 dBu
—
PHONES
8Ω
Residual output noise, phones level
control min.
–88 dBu
Inputs Outputs RL Conditions Min. Typ. Max. Unit
OMNI IN 1-8 OMNI OUT 1-8 600Ω AD + DA, GAIN: –6 dB 114 dB
— OMNI OUT 1-8 600Ω DA Converter 116 dB
