DSP-A595
Ref.
No.
PART NO.
Description Remarks Markets
✻ New Parts
Ref.
No.
PART NO.
Description Remarks Markets
✻ New Parts
65 66
■ MECHANICAL PARTS
1- 1 V2464300 FRONT PANEL BL
1- 1 V2464400 FRONT PANEL TI
1- 4 V2468600 ESCUTCHOEN 3/8
2- 1 V3005400 P.C.B. ASS’Y OPERATION (RT)
2- 1 V3005500 P.C.B. ASS’Y OPERATION (B)
2- 1 V3005600 P.C.B. ASS’Y OPERATION (G)
2- 8 MF229160 S FLEXIBLE FLAT CABLE C&C 29P 160mm
2-11 V2460700 SUB CHASSIS
2-12 V2465500 BUTTON CASE BL
2-12 V2465600 BUTTON CASE TI
2-15 V2466700 BUTTON INPUT BL
2-15 V2466800 BUTTON INPUT TI
2-17 V2467900 ESCUTCHEON, VOL BL
2-17 V2468000 ESCUTCHEON, VOL TI
2-18 V2468300 ESCUTCHEON, PJ BL
2-18 V2468400 ESCUTCHEON, PJ TI
2-21 EP600830 BIND HEAD B-TITE SCREW 3x8 FCRM3-BL
2-22 VN413300
BIND HEAD BONDING B-T. SCREW
3x8 MFZN2-BL
2-23 VT669300 PW HEAD B-TITE SCREW 3x8-8 MFC2
2-24 EP630220 BIND HEAD P-TITE SCREW 3x8 ZMC2-BL
3- 1 V2463200 HEAT SINK
3- 2 V3003700 P.C.B. ASS’Y MAIN (RT)
3- 2 V3003800 P.C.B. ASS’Y MAIN (BG)
3- 3 VV849300 SHEET 19x24
3-11 V2461000 SUPPORT, TR
3-12 VQ368500 PUSH RIVET P3545-B
3-13 VK173200 SCREW, TRANSISTOR 3x15 SP FCM3
3-14 VT669300 PW HEAD B-TITE SCREW 3x8-8 MFC2
3-20 VQ368600 PUSH RIVET P3555-B
6 V3005700 P.C.B. ASS’Y DSP
8 V3004300 P.C.B. ASS’Y INPUT (RT)
8 V3004400 P.C.B. ASS’Y INPUT (BG)
15 XV317A00 POWER TRANSFORMER (RT)
15 XV319B00 POWER TRANSFORMER (BG)
16 VN363700 POWER CORD ASS’Y (G)
16 VV437300 POWER CORD ASS’Y (B)
16 VZ542500 POWER CORD ASS’Y (RT)
17 V2438700 CORD STOPPER #10P1
21 VU590000 BINDING TIE CBTD001B
22 VZ625600 BINDING TIE SE140 L=140
23 MF106250 FLEXIBLE FLAT CABLE 6P 250mm
24 MF211140 S FLEXIBLE FLAT CABLE 11P 140mm
25 MF123180 FLEXIBLE FLAT CABLE 23P 180mm
26 MF113140 FLEXIBLE FLAT CABLE 13P 140mm
30 V2126000 DAMPER T2x10x20
101 VV121300 TOP COVER BL
101 VV121500 TOP COVER TI
102 V2460600 CHASSIS
103 V2462700 REAR PANEL (RT)
103 V2462900 REAR PANEL (B)
103 V2463000 REAR PANEL (G)
105 V2460800 FRAME, TRANSFORMER
109 V2461100 SHIELD CASE
110 VZ332800 SHIELD CASE COVER
112 V2460900 FRAME
120 VS025000 LEG D60xH21
121 V3346400 KNOB D40 BL
121 V3346500 KNOB D40 TI
122 V2467600 KNOB, ENC D30 BL
122 V2467700 KNOB, ENC D30 TI
123 VV311000 KNOB D14 BL
123 VV311400 KNOB D14 TI
124 V2467300 BUTTON, 3/8 BL
124 V2467400 BUTTON, 3/8 TI
128 V2469400 SHEET, WINDOW
129 V3153900 SHHET
131 V2468800 PLATE SIDE L 130 BL
131 V2468900 PLATE SIDE L 130 TI
132 V2469100 PLATE SIDE R 130 BL
132 V2469200 PLATE SIDE R 130 TI
135 VR264400 SPACER H8
136 VQ948200 SPACER FL
138 V2879500 SPACER PCB-M
139 V3198100 DAMPER GUARD (G)
155 VQ368600 PUSH RIVET P3555-B
160 VN413300
BIND HEAD BONDING B-T. SCREW
3x8 MFZN2-BL
161 VY731200
BONDING HEAD TAPPING SCREW
3x10 MFNI33
162 EP600830 BIND HEAD B-TITE SCREW 3x8 FCRM3-BL
163 EP600250 BIND HEAD B-TITE SCREW 3x8 ZMC2-Y
166 EG330030 BIND HEAD SCREW 3x6 FCRM3-BL
167 VT669300 PW HEAD B-TITE SCREW 3x8-8 MFC2
168 VT669400 PW HEAD B-TITE SCREW 3x15-8 MFC2
170 21991500 PW HEAD S-TITE SCREW 4x8-10 FCRM3-BL
171 21991500 PW HEAD S-TITE SCREW 4x8-10 FCRM3-BL BL
171 VH313200 BW HEAD S-TITE SCREW 4x8-10 FNM3-BL TI
176 AA627310 GROUND TERMINAL
178 03700480 HEXAGONAL CAP NUT 4.0 MFNI33
ACCESSORIES
200 V2686300
REMOTE CONTROL TRANSMITTER
RRC4000-7001R (RT)
200 V2686400
REMOTE CONTROL TRANSMITTER
RRC4000-7002R (BG)
200-1 XX702560 LID
BATTERY, MANGANESE SUM-3,AA,R06
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
!
✻
!
!
!
!
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
