24
2-1. PLAYING A SOURCE
1. Set the MASTER VOLUME control to minimum.
2. Turn the power on.
3. Select an input source.
(The selected source is shown by the display panel, the monitor
screen and illumination of the corresponding indicator over the
input selector switches.)
* On the front panel, VCR 1, CD or LD can be selected directly by
pressing the corresponding switch.
4. Play the source.
5. Increase the setting of the MASTER VOLUME control to your
listening level.
Adjust the BASS, TREBLE, BALANCE controls, etc., or select a
desired sound field program. (See page 28.)
NOTE: If a different audio source is selected with the input selector
keys on the remote control unit while enjoying a video source, the
sound from the newly selected audio source is heard, but the picture
from the video source can still be seen.
GENERAL OPERATION
