RX-V459/DSP-AX459/HTR-5935
57
DSP P.C.B. (Side B)
Lead Free Solder Used
• Semiconductor Location
D1 D5
D2 D5
D3 D5
D6 D5
D9 D5
Ref no. Location Ref no. Location
D10 D5
Q2 D5
Q8 D5
Q9 D5
