Yamaha DSP-AZ2 Owner's Manual

81
English
INTRODUCTION PREPARATION
BASIC
OPERAIONT
ADVANCED
OPERATION
ADDITIONAL
INFORMATION
APPENDIX
SPECIFICATIONS
AUDIO SECTION
• Minimum RMS Output Power
Main, Center, Rear, R. Center
(20 Hz to 20 kHz, 0.02% THD, 8 Ω) ............................... 130 W
Front effect
(1 kHz, 0.05% THD, 8 Ω) .................................................. 25 W
• Maximum Power (EIAJ) [General and China models]
Main, Center, Rear, R. Center
(1 kHz, 10% THD, 8 Ω) ................................................... 175 W
Front effect
(1 kHz, 10% THD, 8 Ω) ..................................................... 35 W
• Dynamic Power (IHF)
8/6/4/2 Ω ........................................................ 155/195/250/340 W
• DIN Standard Output Power [Europe and U.K. models]
Main, Center, Rear, R. Center
(1 kHz, 0.7% THD, 4 Ω) .................................................. 190 W
Front effect
(1 kHz, 0.7% THD, 4 Ω) .................................................... 45 W
• Damping Factor (IHF)
20 Hz to 20 kHz, 8 Ω ................................................. 200 or more
• Frequency Response
CD to Main L/R ...................................... 10 Hz to 100 kHz, –3 dB
• Total Harmonic Distortion
20 Hz to 20 kHz, 65 W, 8 Ω, MAIN IN to Main L/R ......... 0.008%
• Signal to Noise Ratio (IHF-A Network)
Phono MM (5 mV) to Main L/R .......................................... 86 dB
CD (250 mV, shorted) to Main L/R, Effect Off .................. 100 dB
• Residual Noise (IHF-A Network)
Main L/R ................................................................ 150 µV or less
• Channel Separation (1kHz/10 kHz)
CD (5.1 kΩ terminated) to Main L/R ........................ 60 dB/45 dB
• Tone Control (Main L/R)
BASS Boost/Cut ...................................................... ±10 dB/50 Hz
TREBLE Boost/Cut ............................................... ±10 dB/20 kHz
BASS EXTENSION .................................................. +6 dB/60 Hz
• Phones Output ........................................................... 150 mV/100 Ω
• Input Sensitivity
PHONO ................................................................... 2.5 mV/47 kΩ
CD, etc .................................................................... 150 mV/47 kΩ
MAIN IN ....................................................................... 1 V/47 kΩ
• Output Level
REC OUT .............................................................. 150 mV/1.2 kΩ
PRE OUT .................................................................. 1.0 V/1.2 kΩ
SUBWOOFER .......................................................... 4.0 V/1.2 kΩ
VIDEO SECTION
• Video Signal Type .......................................................... NTSC/PAL
• Signal to Noise Ratio ............................................................... 50 dB
• Frequency Response (MONITOR OUT)
Composite, S-Video ................................. 5 Hz to 10 MHz, –3 dB
Component ................................................. DC to 60 MHz, –3 dB
GENERAL
• Power Supply
[Europe and U.K. models] ................................... AC 230 V/50 Hz
[China model] ...................................................... AC 220 V/50 Hz
[General model] ........................ AC 110/120/220/240 V, 50/60 Hz
• Power Consumption ............................................................... 500 W
Standby mode ............................................................ 1.2 W or less
• AC Outlets
[Europe model] .................................... 2 (Total 100 W Maximum)
[General and China models] .................. 2 (Total 50 W Maximum)
[U.K. model] ....................................... 1 (Total 100 W Maximum)
• Dimension (W x H x D) ................................... 435 x 191 x 453 mm
(17-1/8" x 7-1/2" x 17-13/16")
• Weight ................................................................. 22 kg (48 lbs 8 oz)
