Yamaha DVX-700 - Connecting Speakers to Subwoofer

14 En
■ Connecting the speakers
Note
Do not connect the power cable of the subwoofer/system control into an AC outlet until all cable connections are
completed.
SYSTEM CONNECTIONS
VIDEO
COMPONENT
PR
VIDEO
OUTPUT
HDMI
OUTPUT
Y
P
B
SYSTEM
CONNECTOR
NS-PSW700
MAINS
SYSTEM
CONNECTOR
DVR - 700
SPEAKERS
SPEAKER IMPEDANCE
:
6 MIN.
Speaker (R)
Subwoofer/system control
DVD controller
Speaker (L)
