2-14
E
DN
UP
000921
EMU01112
Power Trim/Tilt Switches
The power trim/tilt adjusts the motor angle
in relation to the transom. The power trim/tilt
switch is located on the remote control lever
grip. Individual-engine switches are also on
the control cover. Pushing the switch “UP”
trims the motor up, then tilts the motor up.
Pressing the switch “DN” tilts the motor
down and trims the motor down. When the
switch button is released, the motor will
stop in its current position.
NOTE:
8 On the dual engine control, the switch on
the remote control grip controls both
engines at the same time.
8 Refer to the sections “Adjusting Trim
Angle” and “Tilting Up/Down” in Chapter 3
for instructions on usage.
