2-18
E
801023
YAMAHA
x1000 r/min
7
6
5
43
1
2
801011
YAMAHA
001326
HOUR
YAMAHA
w
q
EMU00124
TACHOMETER
This meter shows the engine speed.
EMU00132
TRIM METER (for Power trim/tilt
model)
This meter shows the trim angle of your out-
board.
NOTE:
Memorize the trim angles that work best for
your boat under different conditions. Adjust
the trim angle to the desired setting by
operating the power trim/tilt switch.
EMU00133
DIGITAL HOUR METER
This meter indicates the time elapsed time
by counting the time of engine use.
1 Hours
2 Minutes(×6)
NOTE:
The time counting method can be selected
that it counts while the main switch is “ON”
or the engine is running by operator’s pref-
erence. Consult your Yamaha dealer for
selecting the time counting method.
60H-9-E1-2 3/1/02 9:36 PM Page 19
