Cleaning the Fuel Filter
1) Remove the screws holding the fuel
hose joint assembly. Pull the assembly
out of the tank.
2) Clean the filter (located on the end of
the suction pipe) in a suitable cleaning
solvent. Allow the filter to dry.
3) Replace the gasket with a new one.
Reinstall the fuel hose joint assembly
and tighten the screws firmly.
EMU01462
INSPECTING AND REPLACING
ANODE(S)
Yamaha outboard motors are protected
from corrosion by sacrificial anodes.
Check the anodes periodically. Remove
scales from the surfaces of the anodes.
For inspection and replacement of anodes,
consult a Yamaha dealer.
cC
Do not paint anodes, as this would ren-
der them ineffective.
