Instruments and indicators
47
To return to the normal display
Push the “SET” (set) button, and the over-
heat-alert indicator will start to blink.
Stop the engine immediately if the buzzer
sounds and the overheat device has activat-
ed. Check the cooling water inlet for clog-
ging.
ECM01594
Do not continue to run the engine if the
overheat-alert indicator blinks. Serious
engine damage will occur.
Do not continue to operate the engine if
an alert device has activated. Consult
your Yamaha dealer if the problem can-
not be located and corrected.
EMU46654
6Y8 Multifunction meters
There are two types of 6Y8 Multifunction me-
ters.
6Y8 Multifunction tachometer
6Y8 Multifunction speed & fuel meter
6Y8 Multifunction tachometer
1. Pop-up window
1. Overheat-alert indicator
1. Set button
2. Mode button
1. Tachometer
2. Trim meter
3. Multifunction display
