Operation
61
3. Place the tilt lock lever (if equipped) in
the release/up position.
4. Pull up the shallow water lever (if
equipped).
5. Hold the rear of the top cowling with one
hand and tilt the engine up fully.
6. Push the tilt support knob into the clamp
bracket. Or the tilt support bar will turn to
the lock position automatically.
NOTICE: Do not use the tilt support
lever or knob when trailering the
boat. The outboard motor could
shake loose from the tilt support and
fall. If the motor cannot be trailered in
the normal running position, use an
additional support device to secure it
in the tilt position. For more detailed
information, see page 67.
[ECM01642]
EMU44650
Procedure for tilting up (power tilt
models)
1. Place the remote control lever / gear
shift lever in neutral.
2. Press the power tilt switch “ ” (up) until
the outboard motor has tilted up com-
pletely.
1. Fuel joint
2. Fuel hose
N
ZMU01771
