Yamaha F150 - Specifications and Requirements; Technical Specifications Overview; Dimension and Weight Details; Performance Data

Specifications and requirements
16
EMU40501
Specifications
TIP:
“(SUS)” indicates that the specification is for
the outboard motor when it is equipped with
a stainless steel propeller.
EMU2821Z
Dimension and weight:
Overall length:
920 mm (36.2 in)
Overall width:
548 mm (21.6 in)
Overall height L:
1742 mm (68.6 in) (F150CA, F175CA,
F200CA, LF200CA)
Overall height X:
1869 mm (73.6 in)
Motor transom height L:
516 mm (20.3 in) (F150CA, F175CA,
F200CA, LF200CA)
Motor transom height X:
643 mm (25.3 in)
Dry weight (SUS) L:
226 kg (498 lb) (F150CA, F175CA)
227 kg (500 lb) (F200CA, LF200CA)
Dry weight (SUS) X:
227 kg (500 lb) (F150CA, F175CA,
LF150CA, LF175CA)
228 kg (503 lb) (F200CA, LF200CA)
Performance:
Full throttle operating range:
5000–6000 r/min
Rated power:
110.3 kW (150 HP) (F150CA, LF150CA)
128.7 kW (175 HP) (F175CA, LF175CA)
147.1 kW (200 HP) (F200CA, LF200CA)
Idle speed (in neutral):
650–750 r/min
Power unit:
Type:
4-stroke DOHC L4 16 valves
Total displacement:
2785 cm³ (169.9 c.i.)
Bore × stroke:
96.0 × 96.2 mm (3.78 × 3.79 in)
Ignition system:
TCI
Spark plug (NGK):
LFR6A-11
Spark plug gap:
1.0–1.1 mm (0.039–0.043 in)
Steering system:
Remote steering
Starting system:
Electric starter
Starting carburetion system:
Fuel injection
Valve clearance IN (cold engine):
0.17–0.24 mm (0.0067–0.0094 in)
Valve clearance EX (cold engine):
0.31–0.38 mm (0.0122–0.0150 in)
Battery rating (CCA/SAE):
680–1150 A
Battery rating (MCA/ABYC):
770–1370 A
Battery rating (RC/SAE):
160 minutes
Battery rating (CCA/EN):
640–1080 A
Battery rating (20HR/IEC):
80 Ah
Maximum generator output:
50 A
Lower unit:
Gear shift positions:
Forward-neutral-reverse
Gear ratio:
1.86 (26/14) (F175CA, F200CA,
LF175CA, LF200CA)
2.0 (28/14) (F150CA, LF150CA)
Trim and tilt system:
Power trim and tilt
