Yamaha F150BET User Manual

4-22
6X4 MULTI-FUNCTION TILLER HANDLE
MULTI-FUNCTION TILLER HANDLE KIT (FOR EU & ANZ)
F115B
KIT P/N: 6X4-42102-C0
HANDLE IMMOBILIZER KIT CONTENTS
F30B – F115B
KIT P/N: 6Y8-W0035-C0
* Requires to replace the rigging grommet as follows.
F50 up to F60: 6C5-42725-50
F75 up to F115 (68V): 68V-42725-20
Part name Part No. Q’ty Remarks
STR friction assy 67G-42508-10 1
Stud bolt 90116-10063 2
Locknut 90185-10027 2 M10
Bracket 6EK-42121-00 1
Shift cable 6EK-48321-00 1 820 mm (33.5 in)
Clip 90468-10005 2
Cable clamp 63D-48538-00 2
Throttle cable 6EK-26301-00 1 710 mm (29.1 in)
Clamp 90464-09M42 1
10-pin main harness 6X4-82586-10 1 950 mm (37.4 in)
Clamp 90465-13M24 1
Troll RPM switch assy 6X4-81860-00 1
Part name Part No. Q’ty Remarks
Wire-harness 6Y5-83553-M0 1 2.5 m (8 ft)
Single hub 6Y8-81920-11 2
Wire-lead 6Y8-82117-00 1 For system PWR
Pigtail bus wire 6Y8-82521-51 1 3.6 m (12 ft)
Main bus wire 6Y8-82553-01 1 0.3 m (1 ft)

Yamaha F150BET Specifications

General

Compression Ratio	10.0:1
Full Throttle RPM Range	5000 - 6000 RPM
Lubrication System	Wet Sump
Starting System	Electric
Gear Ratio	1.86:1
Gear Shift	F-N-R
Cooling	Water Cooled
Steering	Remote
Engine Type	4-Stroke
Max Output	150 hp
Operating Range	5000 - 6000 rpm
Fuel Induction System	Electronic Fuel Injection (EFI)
Ignition System	TCI (Transistor Controlled Ignition)
Alternator Output	50 Amp
Exhaust	Through Propeller Hub (Jet Prop)
Shaft Length	25 in
Recommended Fuel	Regular unleaded gasoline (minimum 87 octane)
