3-4
REMOTE CONTROL APPLICATIONS
704 REMOTE CONTROL
Designed for use with electric start models. Best fitted to a boat with center console.
Single lever or Twin lever is available for engine applications.
Two kinds of control box, Premium or Standard type, is selectable to match boat design, cost, etc.
12 3
* Switch panel and extension wire-harness are required to connect to the engine 10-pin harness.
* Throttle opening direction can be reversed.
* Lever location can be changed to its opposite position.
* For further information, see the instruction (P/N:704-2819K-P0) in the package.
Ref.
No.
Part No.
Throttle
PT/T
Lever
Remarks
Push
Pull R L
Twin
1
704-48203-P1 1 1 Premium
704-48205-P1 1 1 1 Premium
704-48206-P1 1 1 1 Premium
2 704-48205-B1 1 1 1 Standard
3 704-48207-P1 1 1 1 Premium
To Next Page
