REMOTE CONTROL APPLICATIONS
704 REMOTE CONTROL DIMENSIONS
Single lever Twin lever
212 (8.35) 106 (4.17)
33 (1.30)
70 (2.76)
94.5 (3.72)
74 (2.91)
105 (4.13)
179.5 (7.07)
55 (2.16)
153 (6.02)
138 (5.43)
6 (0.23)
8 (0.31)
10 (0.39)
57 (2.24)
135.2 (5.32)
39 (1.54)
213 (8.39)
mm (in.)
212 (8.35) 106 (4.17)
33 (1.30)
70 (2.76)
94.5 (3.72)
126 (4.96)
187.5 (7.38)
103.5 (4.07) 90 (3.54)
109.2 (4.29)
108 (4.25)
153 (6.02)
138 (5.43)
135.2 (5.32)
39 (1.54)
213 (8.39)
6 (0.23)
10 (0.39)
10 (0.39)
mm (in.)
