!1
!2
!3
!4
!5
!9
!7
!8
!6
@0
@1
q
w
e
r
t
o
i
!0
u
y
@2
@3
@4
E
2-1
EMU01206
MAIN COMPONENTS
1 Top cowling
2 Top cowling lock lever
3 Oil drain bolt
4 Anti-cavitation plate
5 Trim tab
6 Propeller
7 Cooling water inlet
8 Trim angle adjusting rod
9 Clamp bracket
* 0 Power trim and tilt switch
* q Starter button
* w Recoil starter handle
* e Warning indicator
* r Gear shift lever
* t Tiller handle
* y Steering friction adjusting lever
* u Clamp screw
* i Rope attachment
* o Tilt lock lever
p Flushing device
* a Tilt support knob
* s Remote control box
* d Digital tachometer
* f Fuel tank
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
