E
4-15
When fitting the plug, always clean the
gasket surface and use a new gasket.
Wipe off any dirt from the threads and
screw in the spark plug to the correct
torque.
NOTE:
If a torque-wrench is not available when
you are fitting a spark plug, a good esti-
mate of the correct torque is 1/4 to 1/2 a
turn past finger-tight. Have the spark plug
adjusted to the correct torque as soon as
possible with a torque-wrench.
1 Spark plug gap
2 Spark plug I.D. mark (NGK)
EMU16350
CHECKING TOP COWLING
Check the fitting of the top cowling by
pushing it with both hands.
If the fitting is loose have it repaired by a
Yamaha dealer.
Spark plug torque:
Refer to “SPECIFICATIONS”, page 4-1.
Initial of spark plug
Plug wrench size
I.D. mark
B 21 mm (13/16 in.)
C/BK 16 mm (5/8 in.)
D 18.3 mm (23/32 in.)
