OPERATIONS OF CONTROLS
AND
OTHER FUNCTIONS
EMU00040
FUEL TANK
If your model was equipped with a
portable fuel tank, its function is as fol-
lows.
1 Fuel hose joint
2 Fuel meter (If equipped)
3 Fuel tank cap
4 Air vent screw (If equipped)
EMU00042
Fuel Hose Joint
This connector is provided for connecting
or disconnecting fuel hose.
EMU00044
Fuel Meter
This meter is on the fuel tank cap. It
shows current fuel quantity in the fuel
tank approximately.
EMU00045
Fuel Tank Cap
This cap is for filling fuel. To remove it,
turn it counterclockwise.
EMU00046
Air Vent Screw
This screw is on the fuel tank cap. To
loosen it, turn it counterclockwise.
