Yamaha F25C - Page 98

E
4-25
EMU00397
Installing the Propeller
cC
8 Be sure to install the thrust washer
before installing propeller, otherwise,
lower case and propeller boss may be
damaged.
8 Be sure to use a new cotter pin and
bend the ends over securely.
Otherwise, the propeller could come off
during operation and be lost.
1) Apply Yamaha Marine grease or
Corrosion resistant grease to the pro-
peller-shaft.
2) Install the thrust washer and propeller
on the propeller-shaft.
3) Install the spacer and washer. Tighten
the propeller nut to the specified
torque.
602073
q
w
e
r
t
y
602045*
6
5
4
3
2
1
EMU00976
Removing the Propeller
1) Straighten the cotter-pin 1 and pull it
out using a pair of pliers.
2) Remove the propeller nut 2, washer
3 and spacer 4.
3) Remove the propeller 5 and thrust
washer 6
FT25
65W-9-17-4 3/11/03 10:00 Page 26
