6-21
Outboard Rigging Guide - 2001 Steer. Friction Kit – F30/F40 Tiller Handle
STEERING FRICTION KIT (67C-W0084-00-4D) – F30/F40 TILLER HANDLE [Cont’d.]
• Component parts
REF
NO PART NUMBER DESCRIPTION QTY.
36 67C-26301-00-00 Throttle Cable Ass’y1
37 63D-48538-00-00 Clamp, Cable 1 1
38 90468-10005-00 Clip 1
39 67G-44159-00-4D Handle, gear shift 1
40 90386-26MA3-00 Bush 1
41 97095-08040-00 Bolt 1
42 92995-08600-00 Washer 1
43 67G-44173-00-00 Lever, Shift Control 1
44 90159-06M18-00 Screw, with Washer 2
45 6G8-44191-00-00 Indicator, Shift 1
46 67G-42131-00-00 Cover, Handle Steering 1
47 97885-06016-00 Screw, Pan Head 5
48 92995-06600-00 Washer 5
49 97885-06040-00 Screw, Pan Head 2
50 92995-06600-00 Washer 2
51 63D-42725-00-00 Grommet 1
52 63D-42126-00-00 Friction, Steering Handle Grip 1
53 63D-48154-00-00+ Knob, Throttle 1
54 95380-06600-00 Nut, Hexagon 1
55 91490-20010-00 Pin, Cotter 1
56 664-42119-00-00 Grip,. Steering Handle 1
57 6J0-42137-00-00 Indicator, Throttle 1
58 90269-02M09-00 Rivet 1
59 6G1-42177-00-00 Rubber, Handle 1
60 90386-08032-00 Bush 1
61 90501-23215-00 Spring, Compression 1
62 92903-10600-00 Washer, Plate 1
63 90149-05M13-00 Screw 1
REF
NO PART NUMBER DESCRIPTION QTY.
1 67C-W0084-4D-00 Handle Steering Ass’y1
2 67C-42121-00-04D Bracket 1
3 90101-12M09-00 Bolt 1
4 92990-12200-00 Washer, Plain 2
5 90206-12M22-00 Washer, Wave 1
6 90387-12M02-00 Collar 1
7 90386-12M93-00 Bush 2
8 92990-12600-00 Washer, Plate 1
9 90185-12M12-00 Nut, Self-Locking 1
10 67G-42111-00-4D Handle, Steering 1
11 67C-44100-00-00 Shift Link Ass’y1
12 67C-44104-00-00 . Plate Comp. 1
13 67G-48261-00-00 . Arm Throttle 1
14 67C-42115-00-00 . Shaft, Steering Handle 1
15 650-42152-00-94 . . Gear 1
16 91690-30025-00 . . Pin, Spring 1
17 67G-42159-00-00 . . Stay 1
18 67C-44113-00-00 . Cam Plate, Handle 1
19 63D-48236-00-00 . Roller, Detent 1
20 67C-48119-00-00 . Cover 1
21 67G-42153-00-00 . Shaft, Throttle Control 1
22 67G-44132-00-00 . Bushing 1
23 63D-48237-00-00 . Adaptor 1
24 98785-05014-00 . Screw, Flat Hed 2
25 63D-48238-00-00 . Spring, Detent 1
26 97095-06030-00 Bolt 2
27 92995-06600-00 Washer 2
28 97095-06014-00 Bolt 1
29 92995-06600-00 Washer 1
30 67G-48531-00-00 Bracket, Remote Control 1 1
31 97095-06014-00 Bolt 1
32 67C-48321-00-00 Cable 1
33 90468-10005-00 Clip 1
34 66R-48538-00-00 Clamp, Cable 1 1
35 97095-06014-00 Bolt 1
