Basic components
22
EMU26201
Neutral interlock trigger
To shift out of neutral, first pull the neutral in-
terlock trigger up.
EMU26211
Neutral throttle lever
To open the throttle without shifting into either
forward or reverse, put the remote control le-
ver in the neutral position and lift the neutral
throttle lever.
NOTE:
The neutral throttle lever will operate only
when the remote control lever is in neutral.
The remote control lever will operate only
when the neutral throttle lever is in the closed
position.
EMU26221
Choke switch
To activate the choke system, press in the
main switch while the key is turned to the “”
(on) or “” (start) position. The choke sys-
tem will then supply the rich fuel mixture re-
quired to start the engine. When the key is
released, the choke will switch off automati-
cally.
EMU25911
Tiller handle
To change direction, move the tiller handle to
the left or right as necessary.
EMU25922
Gear shift lever
Pulling the gear shift lever towards you puts
the engine in forward gear so that the boat
moves ahead. Pushing the lever away from
you puts the engine in reverse gear so that the
boat moves astern.
1. Neutral interlock trigger
1. Fully open
2. Fully closed
U6AU11E0.book Page 22 Friday, September 7, 2007 10:51 AM
