DESCRIPTION
3-1
3
EAU10410
Left view
1. Convenience hook (page 4-9)
2. Owner’s tool kit (page 7-1)
3. Seat (page 4-8)
4. Rear turn signal light (page 7-26)
5. Tail/brake light (page 7-24)
6. Air filter element (page7-12)
7. V-belt case air filter element (page 7-13)
8. Engine oil drain bolt A (page 7-10)
9. Engine oil drain bolt B (page 7-10)
1 2 3 4 5
6
9 8 7
ZAUU0676
ZAUU0676
