DESCRIPTION
3-3
3
EAU10430
Controls and instruments
1. Fuel tank cap (page 4-5)
2. Left handlebar switch (page 4-4)
3. Rear brake lever (page 4-5)
4. Speedometer unit (page 4-3)
5. High beam indicator light (page 4-2)
6. Turn signal indicator light (page 4-2)
7. Engine trouble warning light (page 4-3)
8. Fuel gauge (page 4-3)
9. Oil chang indicator (page 4-3)
10. Front brake lever (page 4-5)
11. Right handlebar switch (page 4-4)
12. Keyhole cover (page 4-2)
3
2
1
4 5 6 7 8 9
10
11
12
ZAUU0678
