Yamaha GLADIATOR - Controls;Instruments

17. Clutch Lever (page 3-3, 6-16)
18. Left Hand Switch (page 3-3)
19. Speedometer (page 3-2)
20. Main switch Cum Steering Lock (Page 3-1)
21. Fuel Gauge (page 3-2)
22. Front Brake Lever (page 3-4, 6-16)
23. Throttle Grip (page6-12)
24. Fuel Tank Cap (page 3-5)
25. Turn Indicator Switch (page 3-2)
26. Starter/Kill Switch (page 3-3)
17
18
19 20 21
23
24
25
Controls / Instruments
DESCRIPTION
22
STANDARD VEHICLE
2-3
26
