1. Indicator Screws (1 No.)
Turn signal and taillight
bulb replacement
1. Remove the screws and the
lense.
2. Push the bulb inward and turn it
counterclockwise.
3. Place a new bulb in the socket.
Push the bulb inward and turn it
clockwise until it engages into the
socket.
4. Install the lense and the
screws.
1. Integral Tail lamp
Screws Nos)
Do not over-tighten the screws as
the lense may break.
(2
with Indicators
Front wheel removal
• It is advisable to have a
YAMAHA dealer service the
wheel.
• Securely support the
Motorcycle so there is no
danger of it falling over.
PERIODIC MAINTENANCE AND MINOR REPAIR
6-29
WARNING
CAUTION :
1
1
To Next Page
