1. Storage compartment
Storage compartment
The storage compartment is located
inside the L.H. Side Cover
1. Spring preload adjusting ring
2. Position indicator
Rear shock absorber
adjustment
Each shock absorber is equipped
with a spring preload adjusting ring.
Adjust spring preload as follows.
Turn the adjusting ring in direction a
to increase spring preload and in
direction b to decrease spring
preload. Make sure that the
appropriate notch in the adjusting
ring is aligned with the position
indicator on the rear shock absorber.
Always adjust each shock
absorber to the same setting.
Uneven adjustment can cause poor
handling and loss of stability.
INSTRUMENT AND CONTROL FUNCTIONS
3-9
WARNING
Adjusting
Position
Soft
12345
Hard
Stan-
dard
