Yamaha GLADIATOR - 2 Description; Left View

DESCRIPTION
2-1
Left view
6. Toolkit (page 6-1)
7. Handle Seat (page 3-10)
8. Drive chain free play check window (page 6-19)
9. Side panel (L.H.) lock (page 6-5)
10. Shift pedal (page 3-4)
1. Fuel cock (page 3-6)
2. Starter Lever (page 3-7)
3. Fuse (page 6-26)
4. Battery (page 6-24)
5. Storage Compartment (page 3-9)
STANDARD VEHICLE
2
6
5
43 7
89
1
10
