RX-V340/RX-V340RDS/
HTR-5630/HTR-5630RDS/DSP-AX340
RX-V340/RX-V340RDS/HTR-5630/HTR-5630RDS/DSP-AX340
20
Functions in DIAG mode
In addition to the DIAG menu items, functions as listed
below are available.
Input selection, 6CH input
Center/Rear/Sub-woofer level adjustment
Muting
Power on/off
Master volume
* Functions related to the tuner and the set menu are not
available.
* It is possible to confirm Menu No.11 IF STATUS while
keeping the signal process (operation status) of each
DIAG menu by using the input mode key of the main
unit.
Initial settings used to start DIAG
The following initial settings are used when starting DIAG.
When DIAG is canceled, these settings are restored to
those before starting DIAG.
Master volume: -40dB
Input: DVD (6CH INPUT OFF)
Effect level: 0dB
Audio mute: OFF
Speaker setting: LARGE / BASS OUT = BOTH
DIAG menu: DSP THROUGH (1. ANALOG BYPASS)
●ダイアグ中の機能











●ダイアグ開始時の初期設定









Operation procedure of DIAG menu and
SUB-MENU
There are 15 MENU items, each of which has some SUB-
MENU items.
DIAG menu selection
Main unit: Select the menu using (Forward) and
(Reverse) keys of PRESET/TUNING.
SUB-MENU selection
Main unit: Select the sub-menu using (Forward) and
(Reverse) keys of PROGRAM.
●ダイアグメニューとサブメニューの操作


ダイアグメニューの選択
  

サブメニューの選択
   

DIAG menu selection

SUB-MENU selection

Keys of main unit/本体キー
