EAU18712
Removing and installing
cowlings and panels
The cowlings and panels shown need
to be removed to perform some of the
maintenance jobs described in this
chapter. Refer to this section each time
a cowling or panel needs to be re-
moved and installed.
EAU38191
Cowling A
To remove the cowling
1. Remove the bolts.
2. Slide the cowling slightly forward,
and then pull it upward as shown.
1. Cowling A
2. Cowling B
1
2
1. Cowling C
2. Cowling D
3. Cowling E
4. Cowling F
1. Cowling G
2. Cowling H
3. Cowling I
321
4
1 2
3
1. Bolt
1
