Supplementary Information
75
When the [TONE 3] lamp is turned on:
Knob 1 VOLUME Common Edit [PERFORM]  [EDIT]  [COMMON]  [F2] OUT/MFX  [SF1] OUT 
“Volume”
page 60
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F2] OUTPUT  [SF1]
VOL/PAN  “Volume” of the selected part
page 66
Knob 2 PAN Common Edit [PERFORM]  [EDIT]  [COMMON]  [F2] OUT/MFX  [SF1] OUT  “Pan” page 60
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F2] OUTPUT  [SF1]
VOL/PAN  “Pan” of the selected part
page 66
Knob 3 ASSIGN 1 Common Edit Disabled
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F1] VOICE  [SF6]
OTHER  “Assign1” of the selected part
page 66
Knob 4 ASSIGN 2 Common Edit Disabled
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F1] VOICE  [SF6]
OTHER  “Assign2” of the selected part
page 66
When the [EQ] lamp is turned on:
Knob 5 LOW Common Edit [PERFORM]  [EDIT]  [COMMON]  [F1] GENERAL  [SF3] EQ OFS 
“LOW GAIN”
page 59
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F3] EQ  “LOW GAIN” of
the selected part
page 67
Knob 6 MID F Common Edit [PERFORM]  [EDIT]  [COMMON]  [F1] GENERAL  [SF3] EQ OFS 
“MID FREQ”
page 59
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F3] EQ  “MID FREQ” of
the selected part
page 67
Knob 7 MID Common Edit [PERFORM]  [EDIT]  [COMMON]  [F1] GENERAL  [SF3] EQ OFS 
“MID GAIN”
page 59
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F3] EQ  “MID GAIN” of
the selected part
page 67
Knob 8 HIGH Common Edit [PERFORM]  [EDIT]  [COMMON]  [F1] GENERAL  [SF3] EQ OFS 
“HIGH GAIN”
page 59
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button [F3] EQ  “HIGH GAIN” of
the selected part
page 67
When the [EFFECT] lamp is turned on:
Knob 5 CHO PRESET [PERFORM]  [F6] EFFECT  [SF4] CHORUS  “Preset” page 64
Knob 6 CHO SEND Common Edit [PERFORM]  [EDIT]  [COMMON]  [F2] OUT/MFX  [SF1] OUT 
“ChoSend”
page 60
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F2] OUTPUT  [SF2] EF
SEND  “ChoSend” of the selected part
page 66
Knob 7 REV PRESET [PERFORM]  [F6] EFFECT  [SF5] REVERB  “Preset” page 64
Knob 8 REV SEND Common Edit [PERFORM]  [EDIT]  [COMMON]  [F2] OUT/MFX  [SF1] OUT 
“RevSend”
page 60
Part Edit [PERFORM]  [EDIT]  Number [1] – [4] button  [F2] OUTPUT  [SF2] EF
SEND  “RevSend” of the selected part
page 67
When the [ARP] lamp is turned on:
Knob 5 GATE TIME Common Edit [PERFORM]  ARP [EDIT]  [F1] COMMON  “GateTimeRate” page 57
Part Edit [PERFORM]  ARP [EDIT]  [F5] PLY FX  “GateTimeRate” page 58
Knob 6 OCT RANGE Common Edit Disabled
Part Edit [PERFORM]  ARP [EDIT]  [F5] PLY FX  ”OctaveRange” page 58
Knob 7 UNITMULTIPLY Common Edit Disabled
Part Edit [PERFORM]  ARP [EDIT]  [F5] PLY FX  ”UnitMultiply” page 58
Knob 8 TEMPO [PERFORM]  ARP [EDIT]  [F1] COMMON  “Tempo” page 57
