General specifications
Type
Amp.unit
HF:100W at 5kHz, THD=1%, RL=16 ohms
Bi-Amp 2-way bass reflex powered speaker
(Bi-amp lifier electronic crossover network))
Speaker unit
LF : 38 cm cone
HF : 5 cm Titanium diaphragm compression driver
Frequency Range .................. 50 Hz~16 kHz (-10 dB)
Maximum Output Level .......... 124.5 dB (1m on Axis)
Directional angle .................... 90˚ (H)/40˚ (V)
Dimension (W x H x D) .......... 449 x 683 x 379 mm
Weight ................................... 24.2 kg
Color ...................................... Black (approx.Munsell value:
5PB 2/1)
Tripod diameter pole .............. 35~36 mm
Accessories ........................... Power cord (AC inlet type, 2.5 m)
Maximum Output Power
LF: 300W at 500Hz, THD=1%, RL=4 ohms
Cross over frequency ............. 1.6 kHz (30dB/oct.)
Input Sensitivity ...................... LINE: +4dB*, MIC: -50dB*
Input impedance ..................... LINE: 30 kohms, MIC: 5 kohms
Controls
LEVEL .............. LINE, MIC , MASTER
EQ .................... LOW: 0 (Max.) ~ -10 dB (Min.) at 55 Hz
HIGH: ±3 dB (HF)
Power switch ........................ On/Off
Connectors (all balanced):
LINE in/out ................... XLR-3-31, XLR-3-32, phone
(They are all connected in parallel
and can be used as line outputs.)
MIC in .......................... XLR-3-31
POWER indicator ................ Green LED
Power Requirement USA and Canada ...... 120 V, 60 Hz
Europe ....................... 230 V, 50 Hz
Others ........................ 240 V, 50 Hz
Power Consumption ............. 120 W
Accessor ies ......................... Bracketadapter BAD251 (for
BWS251-400, BCS251, and BBS251)
* 0 dB=0.775 V
For European Model
Purchaser/User Information specified in EN55103-1 and
EN55103-2.
Inrush Current: 25A
Conformed Environment: E1, E2, E3 and E4
