Yamaha MS400 - DIMENSIONS; BLOCK DIAGRAM

MS400
4
DIMENSIONS
BLOCK DIAGRAM
Units: mm
683
379
449
203
241
M8
Remove the cover when you
use optional brackets
LOW CUT P.AMP
P.AMP
Mic Input
IC102
VR101 VR104
VR105
VR103
IC104
IC107 IC108
IC106
IC105
VR102
2
13131
57
51
51
3
2
1
3
IC101
Line
Mic
Master
LPF
HPF
Freq. response
compensation
LF
HF
SPEAKER
SPEAKER
Line Input/Output
LOW
EQ
HIGH
EQ
Phone Jack
HPF
AMP 4/5 AMP 5/5 AMP 1/5
CN102-6
CN101-6
CN102-4
CN101-4
CN201-6
CN103-6
CN201-4
CN203-3(LF-),
CN203-4(LF+)
CN203-1(HF+),
CN203-2(HF-)
CN103-4
