PERIODIC MAINTENANCE AND MINOR REPAIR
6-9
6
CAUTION:
ECA10900
Make sure that the oil filler cap is se-
curely tightened, otherwise oil may
seep out when the engine is run-
ning.
To change the engine oil (with or
without oil filter cartridge replace-
ment)
1. Place the vehicle on a level sur-
face.
2. Remove the cowling. (See page
6-6.)
3. Start the engine, warm it up for
several minutes, and then turn it
off.
4. Place an oil pan under the oil tank
to collect the used oil.
5. Remove the engine oil filler cap
and drain bolt to drain the oil from
the oil tank.
6. Place an oil pan under the engine
to collect the used oil.
7. Remove the engine oil drain bolt to
drain the oil from the crankcase.
NOTE:
Skip steps 8–12 if the oil filter cartridge
is not being replaced.
8. Remove the rectifier/regulator by
removing the bolts.
9. Remove the oil filter cartridge with
an oil filter wrench.
1. Engine oil drain bolt (oil tank)
1. Engine oil drain bolt (crankcase)
1. Rectifier/regulator
2. Bolt
U5YU23E0.book Page 9 Friday, November 23, 2007 8:49 AM
