Description
3-1
3
EAU10411
Left view
12
3
4
5
78,9 6
1. Battery (page 8-28)
2. Seat (page 5-23)
3. Spring preload adjuster (page 5-27)
4. Compression damping force adjuster (page 5-27)
5. Rebound damping force adjuster (page 5-27)
6. Shift pedal (page 5-17)
7. Engine oil drain bolt (page 8-10)
8. Fast compression damping force adjuster (page 5-24)
9. Slow compression damping force adjuster (page 5-24)
