Yamaha MT09SPMC - Right View

Description
3-2
3
EAU10421
Right view
1 2 3,4
5
910 6
7
8
1. Fuses (page 8-30)
2. Fuel tank cap (page 5-19)
3. Spring preload adjuster (page 5-24)
4. Rebound damping force adjuster (page 5-24)
5. Coolant reservoir (page 8-13)
6. Engine oil level check window (page 8-10)
7. Engine oil filler cap (page 8-10)
8. Brake pedal (page 5-18)
9. Rear brake light switch (page 8-19)
10.Rear brake fluid reservoir (page 8-20)
