Controls and instruments
1 2 4
65
7 83
1. Clutch lever (page 5-16)
2. Left handlebar switches (page 5-2)
3. Main switch/steering lock (page 5-1)
4. Instrument panel (page 5-4, 5-7)
5. Right handlebar switches (page 5-2)
6. Front brake fluid reservoir (page 8-20)
7. Throttle grip
8. Brake lever (page 5-17)
